UNI-T UT61E+ 1000V True RMS Digital Multimeter
UNI-T UT61E+ 1000V True RMS Digital Multimeter provides accurate voltage, current, and more, ideal for professional electrical testing and diagnostics.
3,995.00 ج.م
متوفرالكود 6935750561089
اشترِ الآن
شحن لجميع محافظات مصريصلك حتى باب بيتك
الدفع عند الاستلامادفع عند وصول طلبك
غير متأكد أنه يناسب مشروعك؟اسألنا على واتساب - نرد بسرعة
UNI-T UT61E+ 1000V True RMS Digital Multimeter
UT61+ series are reliable true RMS digital multimeters with display counts of 6000 (UT61B+/D+) and 22,000 (UT61E+). It can measure up to 1000V AC/DC.
Equipped with audible and visible alarms, this series can provide warning especially when measuring high voltage/current and temperature.
Features
- True RMS.
- Data hold/backlight.
- Max/Min/Relative mode.
- USB communication.
- Input protection.
- Diode/continuity test.
- NCV (audible/visual alarm).
Specifications
| Specifications | Range | UT61E+ |
| Certifications (UT161 Series only) | CE/RoHS/cETLus | |
| Safety ratings | CAT III 1000V/CAT IV 600V | |
| AC voltage (V) | 1000V | ±(0.8%＋10) |
| DC voltage (V) | 1000V | ±(0.05%＋5) |
| AC current (A) | 20A | ±(0.8%＋10) |
| DC current (A) | 20A | ±(0.5%＋10) |
| Resistance (Ω) | 220MΩ | ±(0.5%＋10) |
| Capacitance (F) | 220mF | ±(3%＋5) |
| Frequency (Hz) | 220MHz | ±(0.01%＋5) |
| Duty cycle (%) | 0.1%~99.9% | ±(2%＋5) |
| Display count | 22000 | |
| Bandwidth (Hz) | 40~10kHz | |
| LPF ACV | √ | |
| ACV+DCV | √ | |
| Transistor hFE | √ | |
| Peak Hold | √ | |
| Analog bar | 46 | |
| General Characteristics | ||
| Power | 1.5V battery (R03) x 4 | |
| Product net weight | 350g | |
| Product size | 190mm x 90mm x 50mm | |
Applications
- Electrical Circuit Testing.
- AC/DC Voltage Measurement.
- Current Measurement.
- Resistance and Continuity Testing.
- Capacitance Measurement.
- Frequency Measurement.
- Diode and Transistor Testing.
Package Contents
- 1 x UNI-T UT61E+ True RMS Digital Multimeter Unit
- 1 Pair x Test Leads
- 1 x Adapter Socket
- 1 x K-Type Thermocouple
- 1 x USB Cable.
- 1 x Download Operation Guide
- 4 x AAA Battery 1.5V
- 1 x User Manual
