5011BS 7-Segment 0.56 inch Common Anode Red

5011BS 7-Segment 0.56 inch Common Anode Red Display is a compact and efficient electronic component designed for displaying numerical information.

4.50 EGP

In stockSKU 300000010734
Buy Now
Shipping across EgyptDelivered to your door
Cash on deliveryPay when your order arrives
Not sure it fits your project?Ask us on WhatsApp - we reply fast
Availability: In Stock
SKU:300000010734
5011BS 7-Segment 0.56 inch Common Anode Red

The 5011BS 7-Segment 0.56 inch Common Anode Red Display is a compact and efficient electronic component designed for displaying numerical information. It features seven individually controllable LED segments arranged to form digits from 0 to 9, along with a decimal point for enhanced functionality. The common anode configuration simplifies the driving circuitry by connecting all anodes together, allowing segments to be activated by grounding their respective cathodes through current-limiting resistors. This display is widely used in applications requiring clear and reliable numerical readouts.

Features:
  • Seven-segment LED display design.
  • Red LED illumination.
  • Common anode configuration.
  • Suitable for numeric and selected character display.
  • Individual segment control.
  • Compatible with digital logic and display driver circuits.
  • Suitable for multiplexed display applications.
  • Compact through-hole display format.
Specifications:

Parameter

Value

Product Type

7-Segment LED Display

Display Size

0.56 inch

Display Color

Red

Display Configuration

7-Segment

LED Configuration

Common Anode

Number of Segments

7

Decimal Point

Typically included; verify the specific model

Display Technology

LED

Emitted Light Color

Red

Mounting Type

Through-Hole

Forward Voltage

Depends on the LED characteristics

Segment Current

Depends on the LED rating and drive circuit

Operating Temperature

Not specified

Package

Single-digit display format; confirm model

Applications:
  • Digital clocks and timers.
  • Electronic counters
  • Voltage and current meters
  • Temperature measurement devices
  • Arduino and microcontroller projects
  • Digital control panels
  • Instrumentation and measurement equipment
  • Numeric indicators and status displays
  • DIY electronic projects.
Package Includes:
  • 1 × 5011BS 7-Segment 0.56 inch Common Anode Red.
Documents:
