The L298N is a high-performance, monolithic, dual full-bridge driver that supports TTL logic inputs. It is designed to drive inductive loads, such as motors and relays, and can be used with a variety of actuators. This IC is housed in a 15-lead Multiwatt or PowerSO-20 package, making it versatile for different applications.

The device contains two independent full-bridge outputs, each capable of controlling a motor or actuator. It allows forward, reverse, and stop control by switching the states of its inputs. The L298N supports a wide operating voltage range and can provide sufficient current to power demanding devices.

This dual driver is capable of managing a total DC current of up to 4A at a voltage of 46V. It incorporates several protection features, including over-temperature protection. The IC operates efficiently with a low saturation voltage, ensuring optimal performance in demanding environments.

Features:

• Operating supply voltage up to 46 V.
• 4.5-7VDC logic supply voltage.
• Total dc current up to 4 A.
• Low saturation voltage.
• Over Temperature Protection.
• Logical “0” input voltage up to 1.5 V (high noise immunity).

Specifications:

Pin Configurations:

Footprint:

Applications:

• Dual brush DC motors.
• Stepper motors.

Package Contents:

• 1x L298N Dual Full-Bridge Driver ICs 46V 4A Multiwatt15 V

L298N
