MCM4164BP15 64Kbit Dynamic RAM IC DIP 16-Pin
MCM4164BP15 is a high‑reliability 64 Kbit dynamic RAM IC in a JEDEC‑standard 16‑pin DIP package, 5 V logic, optimized for vintage computing and memory upgrades.
90.00 EGP
In stockSKU 3496300084906
Buy Now
Shipping across EgyptDelivered to your door
Cash on deliveryPay when your order arrives
Not sure it fits your project?Ask us on WhatsApp - we reply fast
MCM4164BP15 64Kbit Dynamic RAM IC DIP 16-Pin
The MCM4164BP15 is a Motorola-manufactured commercial‑grade 64 Kbit (65,536 × 1‑bit) dynamic random‑access memory chip. It provides fixed +5.0 V ±10 % single‑supply operation, a maximum access time of 150 ns, and a standard JEDEC DIP‑16 pinout. The device supports page‑mode read/write for faster sequential access and offers TTL‑compatible inputs with three‑state output buffers. It is fully cross‑compatible with the original 4164 family of TTL DRAMs.
Features
- Organized as 65,536 Words of 1 Bit.
- Single +5 V operation (±10 %).
- Maximum access time: 150 ns.
- Low power dissipation: 275 mW maximum (Active) and 22 mW maximum (Standby).
- Three-state data output.
- Internal latches for address and data input.
- Early-write common I/O capability.
- 16K-compatible 128-cycle, 2 ms refresh.
- RAS-only refresh mode.
- CAS-controlled output.
- Upward pin compatibility with 16K RAM (MCM4116, MCM4517).
- Fast page-mode cycle time.
Specifications
ABSOLUTE MAXIMUM RATINGS
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Voltage on Any Pin Relative to VSS (Except VCC) | Vin, Vout | –1 to +7 | V |
| Voltage on VCC Supply Relative to VSS | VCC | –1 to +7 | V |
| Operating Temperature Range | TA | 0 to +70 | °C |
| Storage Temperature Range | Tstg | –55 to +150 | °C |
| Power Dissipation | PD | 600 | mW |
| Data Out Current | Iout | 50 | mA |
RECOMMENDED OPERATING CONDITIONS
| Parameter | Symbol | Min | Typ | Max | Unit | Notes |
|---|---|---|---|---|---|---|
| Supply Voltage (Operating Voltage Range) – VCC | VCC | 4.5 | 5.0 | 5.5 | V | 1 |
| Supply Voltage (Operating Voltage Range) – VSS | VSS | 0 | 0 | 0 | V | 1 |
| Logic 1 Voltage, All Inputs | VIH | 2.4 | — | 6.5 | V | 1 |
| Logic 0 Voltage, All Inputs | VIL | −1.0 | — | 0.8 | V | 1 |
PINOUT
Applications
- Restoration of vintage systems including Commodore 64/C128, Atari 800XL, Apple IIe/c and early Macintosh hardware.
- Teaching and experimentation in microcomputer architecture and DRAM timing.
- Maintenance and repair of electronics projects relying on 4164‑series DRAMs.
- Integration into retro-computing kits, arcade hardware, or bus‑compatible boards.
- Use in vintage memory testers and cross-reference modules.
