Specifications
| Type | Description |
| Category | Relays Power Relays, Over 2 Amps |
| Series | G6B |
| Mounting Type | Through Hole |
| Coil Voltage | 16VDC |
| Contact Form | DPST-NO/NC (1 Form A, 1 Form B) |
| Contact Rating (Current) | 5 A |
| Switching Voltage | 250VAC, 30VDC |
| Load – Max Switching | 1900VA, 625W |
| Coil Type | Non Latching |
| Termination Style | PC Pin |
| Seal Rating | Sealed – Fully |
| Operate Time | 10 ms |
| Release Time | 10 ms |
| Operating Temperature | -25°C ~ 70°C |
| Contact Material | Silver Alloy, Cadmium Free |
| Relay Type | General Purpose |
| Base Product Number | G6B-211 |
