Product Attributes
TYPE | DESCRIPTION |
Series | G2R |
Mounting Type | Through Hole |
Coil Voltage | 12VDC |
Contact Form | SPDT (1 Form C) |
Contact Rating (Current) | 10 A |
Switching Voltage | 380VAC, 125VDC – Max |
Coil Current | 43.6 mA |
Coil Type | Non Latching |
Features | – |
Termination Style | PC Pin |
Seal Rating | Sealed – Flux Protection |
Must Operate Voltage | 8.4 VDC |
Must Release Voltage | 1.8 VDC |
Operate Time | 15 ms |
Release Time | 5 ms |
Operating Temperature | -40°C ~ 70°C |
Contact Material | Silver Alloy |
Relay Type | General Purpose |
Coil Resistance | 275 Ohms |
Base Product Number | G2R |
