Power Supply 48V 40A
The Power Supply 48V 40A is a high-performance enclosed switching power supply designed for demanding industrial and electronic applications. Engineered to provide a stable 48VDC output at up to 41.7A, this unit delivers a total output power of 2000W, making it suitable for high-current systems such as CNC machines, LED installations, and automation equipment.
Features:
- High output power up to 2000W.
- Stable 48VDC output with up to 41.7A current.
- Wide input voltage range of 110/220VAC, 50/60Hz.
- Built-in voltage adjustment (V ADJ) for fine tuning.
- Multiple output terminals for flexible connections.
Specifications:
| Parameter | Value |
|---|---|
| Model | S-2000-48 |
| Input Voltage | 110/220VAC |
| Input Frequency | 50/60Hz |
| Output Voltage | 48VDC |
| Output Current | 41.7A |
| Output Power | 2000W |
| Voltage Adjustment Range | ±10% |
| Efficiency | Up to87% |
| Cooling Method | 2 cooling fan |
| Protection | Overload, Overvoltage, Short Circuit |
| Dimensions (L×W×H) | 280×140×65mm |
Configuration:
Applications:
- CNC machines and engraving equipment.
- Industrial automation systems.
- LED lighting and signage systems.
- Robotics and motor control systems.
- Communication equipment and servers.
- Battery charging systems.
- Laboratory and testing equipment.
Package Include:
1x Power-Supply 48V 40A.
