Features
- AC input range selected by switch
- Protections: Short circuit / Overload / Over voltage
Specifications
| Type of power supply | switched-mode |
| Output voltage | 5V DC |
| Output voltage 2 | 15V DC |
| Output voltage 3 | -15V DC |
| Output current | 10 A |
| Output current 2 | 3.5 A |
| Output current 3 | 1 A |
| Number of outputs | 3 |
| Body dimensions | 199x110x50mm |
| Operating temperature | -10…60°C |
| Electrical connection | terminal block |
| Protection | anti-overload OPP, anti-overvoltage OVP, short circuit protection SCP |
| Power supply/converter features | rated parameters obtained at full load |
