Right Angle RF Coaxial Connector for PCB Mount V3
The Right Angle RF Coaxial Connector for PCB Mount V3 is a compact PCB-mounted RF connector designed for applications requiring dependable coaxial signal connections while minimizing board space. Its right-angle configuration allows convenient edge mounting on printed circuit boards, making it suitable for wireless communication devices, RF development boards, antenna interfaces, CCTV equipment, radio systems, and other high-frequency electronic projects. Manufactured from durable metal with plated contacts, it provides excellent mechanical stability and consistent electrical performance. The through-hole solder terminals ensure secure PCB installation and long-term reliability for prototype and production designs.
Features:
- Right Angle Pin PCB Mount F Type Female Jack RF Connector.
- Compact Design for less installation space required and high quality.
- Great replacement for the old or broken one.
- Easy quick connect and disconnect coupling.
- The F-Type connector series is a durable, high-performance threaded interface.
Specifications:
- Body Material : Beryllium Copper
- Female Center Contact Material: Brass
- Insulators : PTFE
- Mounting Type: PCB Mount
- Termination Style: Solder Type
- Orientation: Right Angle
- Connector Type: F -Type Female
- Mounting Type: Through Hole
- Impedance : 50 Ω
- Frequency Range @ DC: (3GHz) to (6GHz)
- Insulation Resistance (min.): 5000 MΩ
- VSWR (max.): 1.3
- Dielectric Withstanding Voltage : 1000 V r.m.s
- Working Voltage: 300 V r.m.s
- Durability: 500 cycles
- Dimensions:
- Mounting base (L * W ): 23.5 * 23.5 mm
- Threaded Connector Length: 14 mm
- Operating Temperature Range: (-50°C) to (+90°C)
Applications:
- Consumer Electronic: Terrestrial television, cable television, universally for satellite television , usually with RG-6/U cable or with RG-59/U cable. Satellite Boxes, set top boxes and cable modems.
- Telecommunications: CATV, CATV Networks.
Package Include:
1x Right Angle RF Coaxial Connector for PCB Mount V3
