SMI-S-212L1 Power Relay 24VDC/250VAC 5A 250VAC 2Poles 8Pin
The SMI-S-212L1 Power Relay is a compact electromagnetic power relay designed for PCB mounting and electrical switching applications. It belongs to the SMI 2-pole relay series and provides two independent changeover contact circuits in a compact through-hole package.
Features:
- 12VDC rated coil voltage.
- 2-pole relay configuration.
- 2Form C / DPDT changeover contacts.
- 5A 250VAC resistive contact rating.
- 5A 24VDC resistive contact rating.
- Approximately 0.54W nominal coil operating power.
- Compact design for high-density PCB mounting.
Specifications:
| Parameter | Value |
|---|---|
| Model | SMI-S-212L1. |
| Series | SMI-2P. |
| Relay Type | Electromagnetic power relay. |
| Protective Construction | Flux proofed. |
| Number of Poles | 2Poles. |
| Contact Form | 2Form C / DPDT. |
| Rated Coil Voltage | 12VDC. |
| Nominal Coil Power | Approximately 0.54W. |
| Contact Rating AC | 5A250VAC, resistive load. |
| Contact Rating DC | 5A24VDC, resistive load. |
| Maximum Switching Current | 5A. |
| Mounting Type | Through-hole PCB mounting. |
| Terminal Count | 8Pins. |
Applications:
- Industrial control equipment.
- Home appliance control circuits.
- Air-conditioning systems.
- Audio equipment.
- Electrical instruments.
- Automation and control boards.
- PCB-based switching circuits.
- AC load switching.
- DC load switching.
- Control circuit isolation.
Package Include:
1x SMI-S-212L1 Power Relay 24VDC/250VAC 5A 250VAC 2Poles 8Pin.
