UNI-T LM576R Laser Levels
The UNI-T LM576R 16-Line Laser Level is a professional red-laser leveling instrument designed to provide accurate horizontal and vertical reference lines for construction, installation, decoration, and layout applications. It uses a high-brightness red laser source with 16 laser lines and 360° emission, allowing reference lines to be projected around the working area for convenient alignment and leveling.
Features:
- 16-line red laser projection.
- High-brightness 635nm±10nm red laser.
- Class II laser.
- Horizontal accuracy of ≤±3mm/10m.
- Vertical accuracy of ≤±3mm/10m.
- 360° laser emission.
- Automatic self-leveling function.
- Self-leveling range of ±(3±1)°.
- Self-leveling time of less than 3 seconds.
Specifications:
| Parameter | Value |
|---|---|
| Brand | UNI-T |
| Model Number | LM576R |
| Product Type | 16-Line Laser Level |
| Laser Type | Red, High Brightness |
| Laser Lines | 16 Lines |
| Laser Wavelength | 635nm±10nm |
| Laser Class | Class II |
| Horizontal Accuracy | ≤±3mm/10m |
| Vertical Accuracy | ≤±3mm/10m |
| Laser Linewidth | ≤5mm±1/10m |
| Brightness Adjustment | 3 Levels |
| Emission Angle | 360° |
| Self-Leveling Range | ±(3±1)° |
| Self-Leveling Time | <3s |
| Leveling Method | Magnetic Damping, Pendulum |
| Alarm Mode | Buzzer + Flashing Laser Lines |
| Operating Range | Radius >30m at Maximum Brightness |
| Minimum Wall Distance | 10mm |
| Minimum Ground Distance | 15mm |
| Diagonal Mode | Yes |
| Remote Control | Yes |
| Battery Type | Rechargeable Lithium Battery |
| Battery Voltage | 3.7V |
| Battery Capacity | 6000mAh |
| Battery Life | >30h |
| Charging Interface | Type-C |
| Operating Temperature | -10 to +50°C |
| Dimensions | 135×87×150mm |
Applications:
- Stair installation and alignment.
- Furniture installation.
- Doors and windows installation.
- Electrical installation and layout.
- Residential construction.
- Interior decoration.
- Wall and ceiling alignment.
- Flooring and tiling layout.
- Cabinet and fixture installation.
- General construction and renovation work.
- Horizontal and vertical reference-line projection.
- Professional measurement and layout tasks.
Package Include:
- 1x Laser level
- 1x Remote control
- 1x 6000mAh lithium battery
- 1x User manual
- 1x Wall-mounted bracket+iron plate
- 1x Type-C charging cable
- 1x Toolbox
