UNI-T UPO2102 Mixed-signal Oscilloscope 2-Channels 100MHZ
The UNI-T UPO2102 is a 100 MHz, 2‑channel mixed-signal digital phosphor oscilloscope.
40,795.00 EGP
In stockSKU 3496300116058
Buy Now
Shipping across EgyptDelivered to your door
Cash on deliveryPay when your order arrives
Not sure it fits your project?Ask us on WhatsApp - we reply fast
UNI-T UPO2102 Mixed-signal Oscilloscope 2-Channels 100MHZ
The UNI-T UPO2102 is a high-performance digital oscilloscope designed for precise measurement and analysis in electronics testing. Featuring two analog channels with a 100MHz bandwidth and a real-time sampling rate of 2GSa/s, it offers a memory depth of 56Mpts per channel and a waveform capture rate of up to 1,000,000 waveforms per second in Fast Acquire mode. Its 8-inch capacitive touchscreen display supports intuitive gesture-based operations, enhancing user efficiency. With the optional UT-M15 logic probe, the UPO2102 can function as a mixed-signal oscilloscope (MSO), enabling simultaneous analysis of analog and digital signals. This versatility makes it ideal for applications in embedded systems, automotive electronics, and educational settings.
Features:
- 100MHz bandwidth with 2 analog channels.
- Real-time sampling rate of 2GSa/s.
- Memory depth of 56Mpts per channel.
- Waveform capture rate up to 1,000,000 wfms/s.
- 8-inch TFT LCD capacitive touchscreen with 800×480 resolution.
- Comprehensive trigger functions: Edge, Pulse, Video, Slope, Runt, Over Amplitude.
- Pulse, Delay, Timeout, Duration, Setup/Hold, Nth Edge, Pattern, Area Trigger.
- Automatic measurement of 36 waveform parameters.
- Optional mixed-signal capability with UT-M15 logic prob.e
- Interfaces: USB Host, USB Device, LAN, EXT Trig, AUX Out (Trig Out, Pass/Fail),
VGA. - Additional functions: Bode Plot, Web access/control, SCPI programmable, XY
mode, Multi-Scopes with independent time base. - Ultra Phosphor 2.0 display with 256-level grayscale.
- 4 Mpts Enhanced FFT with Waterfall Chart.
Specifications:
| Specification | Details | ||
|---|---|---|---|
| Model Number | UPO2102 | ||
| Scope Type | UPO | ||
| Bandwidth | 100MHz | ||
| Channels | 2 Analog | ||
| Real-Time Sample Rate | 2GSa/s | ||
| Rise Time | ≤3.5ns | ||
| Memory Depth | 56Mpts | ||
| Waveform Capture Rate | 1,000,000 wfms/s | ||
| Input Impedance (Analog) | (101 kΩ ±1%) | (16 pF ±1 pF) | |
| Input Impedance (Digital) | – | ||
| Waveform Generator | No | ||
| Display | 8-inch TFT LCD | ||
| Touchscreen | YES | ||
| Shipping Dimensions | 19 in × 8 in × 12 in | ||
| Shipping Weight | 4.5 kg |
Applications:
- Debugging embedded systems with analog and digital signals.
- Analyzing power electronics, including waveforms and transients.
- Diagnosing automotive control systems.
- Educational laboratories and research projects.
- Monitoring and troubleshooting industrial automation systems.
Package Includes:
- Digital Oscilloscope
- 2 x Oscilloscope Probes
- Power Cord
- USB 2.0 Printing Cable
Data Sheet:
