UNI-T UT195E Professional Multimeter
Built for harsh industrial environments, the UNI-T UT195E Professional Multimeter exudes rugged reliability. Featuring an IP65 rating and 2-meter drop proofing, it resists dust, moisture, and shocks—ensuring dependable performance even under demanding conditions. Its rubberized housing offers a sturdy, secure grip for safe handling.
Engineered with practical functionality, the UT195E boasts a bright 6000-count display and a responsive 31-segment analog bar that delivers clear, rapid insights into measurements. An integrated flashlight illuminates dim work areas, while data hold, auto backlight, and auto power-off features enhance convenience and usability.
Equipped with True RMS measurement, the device ensures accuracy even in waveform-distorted scenarios. Safety is paramount with CAT III 1000 V and CAT IV 600 V ratings. The inclusion of LoZ (low impedance) voltage mode guards against ghost readings. Altogether, the UT195E blends resilience, intuitive design, and professional-grade measurement confidence into one compact instrument.
Feature:
- IP65 environmental protection (dust and water resistance).
- 2-meter drop proofing.
- True RMS measurement.
- LoZ (low impedance) voltage mode.
- High-resolution 6000-count LCD display.
- 31-segment analog bar graph.
- Integrated flashlight.
- Auto backlight (light sensor controlled).
- Data Hold function.
- MAX/MIN recording functionality.
- Auto power-off.
- CAT III 1000 V and CAT IV 600 V safety ratings.
Specifications:
| Specifications | Range | UT195E |
| DC voltage (V): | 1000V | ±(0.5%+3) |
| AC+DC: | 750V | ±(0.7%+3) |
| LoZ ACV: | 600V | ±(2%+3) |
| DC current (A): | 20A | ±(0.8%+3) |
| AC current (A): | 20A | ±(1%+3) |
| Resistance (Ω): | 60MΩ | ±(0.8%+2) |
| Capacitance: | 60mF | ±(3%+5) |
| Frequency: | 60Hz~10MHz | ±(0.1%+4) |
| Duty cycle: | 0.1%~99.9% | ±(2%+5) |
| Features | ||
| Display count: | 6000 | |
| Display interface (LCD): | Single | |
| Measurement sampling rate: | times/s | 3 |
| Analog bar sampling rate: | times/s | 10 |
| Analog bar: | 31 sections | √ |
| True RMS: | √ | |
| AC voltage frequency response: | 45~400Hz | |
| AC current frequency response: | 45~400Hz | |
| Diode/Continuity test: | 3.5V | |
| Peak hold: | 250μs | |
| Auto/Manual range: | √ | |
| Continuity buzzer: | √ | |
| Low battery indication: | √ | |
| Data hold/Auto power off: | √ | |
| MAX/MIN: | √ | |
| Function selection: | √ | |
| Flashlight/Auto backlight: | √ | |
| General Characteristics | ||
| Power: | 9V battery | |
| LCD size: | 66mm x 51mm | |
| Product Color: | Red and grey | |
| Product net weight: | 437g | |
| Product size: | 195mm x 95 mm x 58mm | |
Applications:
- Industrial Electrical Maintenance.
- Factory Equipment Troubleshooting.
- Field Service Operations.
- Construction and Facility Management.
Package Contents:
- 1x UNI-T UT195E Professional Digital Multimeter
- 1x Test Probes
- 1x 9 V Battery
- 1x Carrying Bag
- 1x User Manual (English, with options in German/French/Spanish)
