YH-48W Lithium-ion Battery Charger 6S 24V 2A With GX16 3-pin Connector
The YH-48W Lithium-ion Battery Charger 6S 24V 2A With 3 Pin Jack is a reliable charger designed specifically for 6-cell (6S) lithium-ion battery packs. It provides a regulated charging output suitable for batteries with a nominal voltage of 21.6V and a full-charge voltage of 25.2V, ensuring safe and efficient charging performance. Its compact desktop enclosure makes it ideal for both personal and industrial applications.
Built with integrated protection circuitry, this charger helps protect connected battery packs against over-voltage, over-current, and short-circuit conditions. The charger features a 3-pin charging connector for secure battery connection and an IEC C8 AC input, allowing the use of a detachable AC power cord for convenient operation in various regions.
Features:
- Designed for 6S lithium-ion battery packs.
- Stable constant voltage and constant current charging.
- Compact desktop enclosure.
- High charging efficiency.
- Secure 3-pin charging connector.
- IEC C8 AC power input.
- Durable insulated housing.
- Suitable for continuous operation.
- Simple plug-and-charge operation.
Specifications:
| Specification | Value |
|---|---|
| Model | YH-48W |
| Battery Type | Lithium-ion |
| Battery Configuration | 6S |
| Rated Output Voltage | 24V |
| Full Charge Voltage | 25.2V DC |
| Output Current | 2A |
| Output Power | 48W |
| Connector Cable Length | 70cm |
| Power Plug Length | 90cm |
| Adapter Dimensions | 33x55x113mm |
| LED Indicator | Yes |
| AC Input Connector | IEC C8 |
| Input Voltage | 100–240VAC |
| Input Frequency | 50/60Hz |
| Charging Method | CC/CV (Constant Current / Constant Voltage) |
| Housing Type |
GX16 3-pin Connector |
Pinout:
| Pin | Description |
|---|---|
| Pin 1 | Battery Positive (+) |
| Pin 2 | Battery Negative (-) |
| Pin 3 | Detection / Auxiliary (connector configuration may vary depending on the battery pack) |
Applications:
- 6S lithium-ion battery packs.
- Electric scooters.
- Portable power equipment.
- Medical equipment batteries.
- Industrial battery-powered devices.
- Robotics.
- DIY battery packs.
- Backup power systems.
- Portable electronic equipment.
- Rechargeable battery maintenance.
Package Includes:
- 1 × YH-48W Lithium-ion Battery Charger 6S 24V 2A With GX16 3-pin Connector.
- 1 × Power Cable.
