Zynq UltraScale+ MPSoC ZCU102 Evaluation Kit
- Part Number: EK-U1-ZCU102-G
- Device Support: Zynq UltraScale+ MPSoC
288,000.00 EGP
Buy NowLast Updated on March 23, 2026 by Muhammad Hamdi
Product Description
The ZCU102 Evaluation Kit enables designers to jumpstart designs for automotive, industrial, video, and communications applications. This kit features a Zynq™ UltraScale+™ MPSoC with a quad-core Arm® Cortex®-A53, dual-core Cortex-R5F real-time processors, and a Mali™-400 MP2 graphics processing unit based on 16nm FinFET+ programmable logic fabric by AMD. The ZCU102 supports all major peripherals and interfaces, enabling development for a wide range of applications.
Key Features & Benefits
- Optimized for quick application prototyping with Zynq UltraScale+ MPSoC
- DDR4 SODIMM – 4GB 64-bit w/ ECC attached to processing system (PS)
- DDR4 Component – 512MB 16-bit attached to programmable logic (PL)
- PCIe® Root Port Gen2 x4, USB3, Display Port, and SATA
- 4x SFP+ interfaces for Ethernet
- 2x FPGA Mezzanine Card (FMC) interfaces for I/O expansion, including 16 16.3Gb/s GTH transceivers and 64 user-defined differential I/O signals
Featured AMD Devices
Featuring the Zynq UltraScale+ XCZU9EG-2FFVB1156 MPSoC
| System Logic Cells (K) | 600 |
|---|---|
| Memory (Mb) | 32.1 |
| DSP Slices | 2,520 |
| Maximum I/0 Pins | 328 |
PRODUCT INFORMATION
Specifications
Board Features
Featuring the ZCU102 Evaluation Board
Configuration
- Onboard JTAG configuration circuitry to enable configuration over USB
- Dual Quad-SPI flash memory
- Boot from SD card
Memory
- PS 4GB DDR4 64-bit SODIMM w/ ECC
- PL 512MB DDR4 component memory ([256 Mb x 16] devices) at 1200MHz / 2400Mbps DDR
- 8KB IIC EEPROM
- Dual 64MB Quad SPI flash
- SD card slot
Control & I/O
- 6x Directional Push Buttons (5x PL, 1x PS)
- DIP switches (8x PL)
- PMBUS & System Controller MSP430 for power, clocks, and I2C bus switching
- USB2/3 (MIO ULPI and 1 GTR)**
Expansion Connectors
- 2x FMC-HPC connectors (16 GTH Transceivers, 64 differential user defined signals)
- 2x PMOD headers
- IIC
Communication & Networking
- RGMII communications at 10, 100, or 1000 Mb/s. Serial GMII interface-supports a 1 Gb/s SGMII interface
- 4x SFP+ cage
- SMA GTH support (4x SMA Tx/Rx connectors)
- UART To USB bridge
- RJ45 Ethernet connector
- SATA (1 x GTR)**
- PCIe Gen2x4 Root Port**
Display
- HDMI video input and output (3 GTH)
- External Retimer device driving an HDMI output connector
- 9x GPIO user LEDs (8x PL, 1x PS)
- VESA DisplayPort 1.2 source-only controller supports up to two lanes of main link data at rates of 1.62 Gb/s, 2.70 Gb/s, or 5.40 Gb/s.
Clocking
- Programmable clocks
- System clocks, user clocks, jitter attenuated clocks
- 2x SMA MGT input clocks
Power
- 12V wall adapter or ATX
** Switch enables either PCIe Root Port OR SATA, USB2/3 & DisplayPort
What’s Inside
- ZCU102 Evaluation Board
- Access to a full seat of Vivado™ Design Suite: Design Edition
- Ethernet Cable
- Targus USB-3
- USB3 Adapter
- USB Micro Cable
- Power Cords and Adapter
- Access to SDSoC Environment
