BTA08-600B 8A 600V Two-way Thyristor TRIAC TO-220AB
The BTA08-600B is a high-performance TRIAC designed for efficient AC switching in a variety of applications, including light dimmers, motor speed controllers, and heating regulation systems. This device features a TO-220AB package, providing excellent thermal management and ease of integration into power circuits. The BTA08-600B operates with an RMS on-state current of 8A, making it ideal for medium-power applications requiring reliable switching performance.
Features:
- RMS on-state current of 8A.
- Peak non-repetitive surge current up to 80A.
- High surge capability and low thermal resistance.
- Low gate trigger current for efficient control.
Specifications:
| Product Attribute | Attribute Value |
| Product Category: | Triacs |
| Series: | BTA08 |
| On-State RMS Current – It RMS: | 8 A |
| Non Repetitive On-State Current: | 80 A |
| Rated Repetitive Off-State Voltage VDRM: | 600 V |
| Off-State Leakage Current @ VDRM IDRM: | 5 uA |
| On-State Voltage: | 1.55 V |
| Holding Current Ih Max: | 50 mA |
| Gate Trigger Voltage – Vgt: | 1.3 V |
| Gate Trigger Current – Igt: | 100 mA |
| Minimum Operating Temperature: | – 40 C |
| Maximum Operating Temperature: | + 125 C |
| Mounting Style: | Through Hole |
| Package/Case: | TO-220-3 |
| Current Rating: | 8 A |
Pin Configuration:
Applications:
- AC power switching.
- Light dimmers and phase control.
- Motor speed control circuits.
- Heater regulation systems.
- Static relays.
Package Include:
1x BTA08-600-B 8A 600V Two-way Thyristor TO-220AB TRIAC
