N-KZ-3 N-Type Straight Female Socket Cable Connector for RG58/RG142 50 ohm
The N-KZ-3 is a straight N-Type female socket cable connector designed specifically for RG58 50-ohm coaxial cable applications. It provides a standard threaded N-Type female interface for connecting the terminated cable to antennas, RF equipment, wireless communication devices, and other N-Type male interfaces.
Its straight cable-mount configuration provides a direct coaxial connection while maintaining a secure mechanical coupling. The connector is suitable for custom RF cable assemblies, antenna installations, communication systems, and RF testing applications where a reliable 50-ohm connection is required.
Features
- Straight N-Type female socket.
- Cable-mount design.
- Designed for RG58 coaxial cable.
- Secure threaded coupling.
- Suitable for 50-ohm RF systems.
- Suitable for custom coaxial cable assemblies.
- Reliable mechanical and electrical connection.
- Suitable for antenna and communication applications.
Specifications
| Specification | Value |
|---|---|
| Product Type | RF Coaxial Cable Connector |
| Model | N-KZ-3 |
| Connector Series | N-Type |
| Connector Type | Female Socket |
| Gender | Female |
| Configuration | Straight |
| Mounting Type | Cable Mount |
| Compatible Cable |
RG58/RG142/RG223/RG303 |
| Impedance | 50 Ohm |
| Coupling Type | Threaded |
| Connection Type | Coaxial |
| Application | RF / Wireless Communication |
Applications
- RG58 coaxial cable assemblies.
- RF antenna systems.
- Wireless communication equipment.
- Radio communication systems.
- RF test and measurement equipment.
- Antenna cable termination.
- Custom RF cable fabrication.
- Coaxial signal connections.
- RF laboratory projects.
Package Included:
- 1 × N-KZ-3 Straight Female Socket Cable Connector.
- 1 × Gold-Plated Center Contact Pin.
- 1 × Crimp Ferrule (Sleeve).
