NDL200N301 EL Backlight Inverter Driver IC DIP-14
The NDL200N301 EL Backlight Inverter Driver IC is a dedicated integrated circuit designed to drive electroluminescent (EL) panels, EL lamps, and EL wires from a low-voltage DC power source. It converts a low DC input into a high-frequency AC output required to illuminate EL lighting elements efficiently. Packaged in a standard DIP-14 through-hole package, the device is suitable for new circuit designs, maintenance, repairs, and prototype development where reliable EL lighting control is required.
Features:
- Designed for driving electroluminescent (EL) panels, lamps, and wires.
- Converts low-voltage DC input into high-frequency AC output.
- Low-voltage operation suitable for battery-powered applications.
- Standard DIP-14 through-hole package.
- Compact integrated inverter solution.
- Simplifies EL lighting circuit design.
- Suitable for portable electronic devices.
- Reliable operation for EL backlighting applications.
- Easy PCB assembly and replacement.
- Ideal for repair, maintenance, and development projects.
Specifications:
| rameter | Value |
|---|---|
| Model | NDL200N301 |
| Product Type | EL Backlight Inverter Driver IC |
| Package | DIP-14 |
| Mounting Type | Through Hole |
| Supply Voltage | 3V – 5.5V DC (Typical) |
| Maximum Supply Voltage | 6V DC |
| Output Type | High-Frequency AC |
| Output Voltage | Approximately 70V – 100V AC |
| Output Current | Approximately 80mA – 100mA |
| Output Frequency | Approximately 500Hz – 600Hz |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Compatible Loads | EL Panels, EL Wires, EL Lamps |
Applications:
- EL Panel Driver.
- EL Wire Driver.
- EL Lamp Driver.
- LCD Display Backlighting.
- Automotive Dashboard Lighting.
- Industrial Control Panels.
- Decorative EL Lighting.
- Consumer Electronics.
- Portable Electronic Devices.
- Instrument Panel Illumination.
Package Include:
1x NDL200N301 EL Backlight Inverter Driver IC DIP-14.
