NMB 2806GL-04W-B39 DC Fan 12V 0.17A 70x70x15mm (USED LIKE NEW)
The NMB 2806GL-04W-B39 is a compact and efficient DC brushless cooling fan designed for applications where space is limited but reliable airflow is required. With its slim 70×70×15mm profile, it is ideal for use in networking equipment, small servers, projectors, and electronic enclosures. Despite its low-profile design, it delivers stable airflow and quiet operation, making it suitable for maintaining safe operating temperatures in sensitive components.
This unit is offered in “used like new” condition, providing a cost-effective solution without compromising performance. Operating at 12V with a typical current around 0.17–0.19A, it offers a good balance between airflow and power consumption. The fan usually features a 3-wire configuration, allowing tachometer feedback for speed monitoring. NMB fans are known for their durability, precision engineering, and long service life in continuous-use environments.
Features:
- Slim and space-saving design.
- Reliable and long operational lifespan.
- Low noise and stable performance.
- Suitable for continuous operation.
- Efficient airflow for compact systems.
- Low vibration and smooth rotation.
- Industrial-grade build quality.
- Supports speed monitoring (tachometer).
Specifications:
| Parameter | Value |
|---|---|
| Brand | NMB (MinebeaMitsumi) |
| Model | 2806GL-04W-B39 |
| Size | 70 x 70 x 15 mm |
| Supply Voltage | 12 V DC |
| Current | 0.17 A |
| Power Consumption | 2.04 W |
| Speed | 2500 ~ 3000 RPM |
| Airflow | 15 ~ 20 CFM |
| Static Pressure | 0.06 ~ 0.10 inH₂O |
| Noise | 20 ~ 28 dBA |
| Bearing Type | Dual Ball Bearing |
| Life Expectancy | 60,000 ~ 70,000 hours @ 25°C |
Applications:
- Network switches and routers.
- Small servers and storage systems.
- Projectors and AV equipment.
- Industrial control panels.
- Embedded systems.
- Compact electronic enclosures.
Package Includes:
- 1x NMB 2806GL-04W-B39 DC Fan 12V 0.17A 70x70x15mm (USED LIKE NEW).
