PG-16 Nylon Waterproof Cable Gland
The PG-16 Waterproof Cable Gland is a compact cable-entry fitting designed to provide secure cable retention and a reliable seal where cables pass through an enclosure. Its PG16 threaded body and compression sealing mechanism grip the cable while helping prevent dust and water from entering the enclosure. Typical PG16 nylon cable glands accommodate cables around 10–14 mm in diameter.
The gland is well suited for electrical panels, automation equipment, junction boxes, machinery, outdoor enclosures, and general cable-management applications. Nylon/polyamide PG16 versions are commonly available with IP68 protection, making them suitable for installations requiring protection against dust and water ingress when correctly installed within the specified cable range.
Features:
- Waterproof and dust-resistant cable entry.
- PG16 threaded design.
- Durable nylon/polyamide construction.
- Compression sealing mechanism.
- Secure cable retention.
- Provides cable strain relief.
- Suitable for indoor and outdoor installations.
- Corrosion-resistant construction.
- Easy panel installation.
- Suitable for electrical and industrial enclosures.
Specifications:
| Color | gray |
| Cable diameter range, mm | 10-14 |
| Body material | polyamide |
| Sealing material | oil-resistant rubber |
| Protection class | ІР68 |
| Altitude above sea level, m | 2000 |
| Operating temperature range, °C | -40…+60 |
| Storage temperature range, °C | -50…+70 |
Applications:
- Electrical control panels.
- Junction boxes.
- Industrial automation equipment.
- Outdoor electrical enclosures.
- Power distribution boxes.
- Machinery and motor wiring.
- LED lighting enclosures.
- Control cabinets.
- Communication equipment.
- Cable management and strain relief.
Package Includes:
- 1x PG-16 Nylon Waterproof Cable Gland.
