PIC16F866-I/SP PDIP-28 Microcontrollers IC
The PIC16F866-I/SP is a microcontroller from the PIC16 series, built on a high-performance RISC architecture. It features an 8-bit CPU with a wide range of built-in peripherals, including analog-to-digital conversion and serial communication options. The microcontroller is designed to provide efficient performance for a variety of embedded applications.
It operates at speeds up to 20 MHz with a 200 ns instruction cycle, offering fast execution and responsiveness. The internal memory consists of Flash Program Memory and RAM, and it includes advanced power-saving features, such as a low-power sleep mode. Its versatile I/O ports make it suitable for various control and signal processing tasks.
The PIC16F866-I/SP operates within a broad voltage range (2.0V to 5.5V) and supports industrial and extended temperature ranges. It also incorporates features like brown-out reset, watchdog timer, and power-on reset to enhance reliability and ensure stable operation in various environmental conditions.
Features:
- High-speed RISC architecture.
- 8-bit CPU with 35 instructions.
- Wide operating voltage range (2.0V–5.5V).
- Low standby current (50 nA)..
- Built-in A/D Converter with 10-bit resolution.
- Multiple timer and serial communication modules.
- Programmable code protection.
- High endurance Flash and EEPROM cells.
- In-circuit debugging support.
Specifications:
| Characteristic | Value |
|---|---|
| Program Memory: | 8K x 14 bits |
| Data Memory (RAM): | 368 bytes |
| EEPROM Memory: | 256 bytes |
| I/O Pins: | 24 |
| Operating Voltage Range: | 2.0V – 5.5V |
| Maximum Clock Speed: | 20 MHz |
| Operating Temperature Range: | -40°C to 125°C |
| Flash Endurance: | 100,000 write cycles |
| EEPROM Endurance: | 1,000,000 write cycles |
Pinout Diagram:
Footprint:
Applications:
- Motor control systems.
- Power management applications.
- Signal processing and sensor applications.
- Automotive embedded systems.
- Communication interfaces (I2C, SPI, UART).
- Industrial control systems.
Package Contents:
- 1x PIC16F866-I/SP PDIP-28 Microcontrollers IC
