Power Supply 12V 20A
This high-performance, industrial-grade 12V 20A (240W) Switching Power Supply (SMPS) is engineered to convert AC mains voltage into a highly stable and regulated 12V DC output. Encased in a rugged, perforated metal enclosure, it utilizes an efficient mesh design to maximize natural convection heat dissipation without requiring loud external fans.
Features
- Regulated & Clean Output
- Premium Thermal Management
- Multi-Channel Terminal Block
- Visual Status LED
Specifications
| Parameter | Specification |
|---|---|
| Input Voltage Range | AC 110V / 240V |
| Output Voltage | DC 12V |
| Output Current Range | 20A (Maximum) |
| Rated Output Power | 240W |
| Frequency Range | 50 / 60 Hz |
| Dimensions | 20 x 11 x 5 cm |
| Weight | 488 g |
| Enclosure Type | Enclosed Perforated Metal Casing (Convection Cooled) |
Applications
- LED Lighting
- Surveillance Systems
- 3D Printing & CNC Machines
- Industrial & DIY Automation
Package Content
- 1 x Power Supply 12V 20A
