Power Supply 15V 15A
The Power Supply 15V 15A 225W Switching (S-225-15 Type) is a high-performance AC to DC converter designed to deliver stable and efficient 15V DC output for a wide range of electronic and industrial applications. With a maximum output current of 15A and total output power of 225W, this unit is ideal for medium to high-power systems requiring reliable voltage regulation.
Features:
- Stable 15V DC output with 15A current capacity.
- Output power up to 225W.
- Dual input voltage 110V/220VAC selectable via switch.
- Adjustable output voltage.
- High efficiency.
Specifications:
| Parameter | Value |
|---|---|
| Model Type | S-225-15 |
| Output Voltage | 15VDC |
| Output Current | 15A |
| Output Power | 225W |
| Input Voltage | 110/220VAC Switch Selectable |
| Input Voltage Range | 90-264VAC |
| Input Frequency | 47-63Hz |
| Efficiency | Up to84% |
| Cooling Method | Natural Air Cooling |
| Operating Temperature | -20°Cto+60°C |
| Protection Functions | Overload, Overvoltage, Short Circuit, Over-temperature |
Configuration:
Applications:
- LED lighting systems and strips.
- CCTV and security systems.
- Industrial automation equipment.
- CNC machines and control systems.
- Communication equipment.
- DIY electronics and embedded systems.
Package Include:
1x Power Supply 15V 15A 225W.
