Toshiba 2SK1356 N-Channel Power MOSFET 900V 3A TO-220F
High-speed 900V, 3A N-Channel power MOSFET. The Toshiba 2SK1356 is ideal for reliable switching in DC-DC converters, motor drives, and power supplies.
30.00 EGP
In stockSKU 3496300131105
Buy Now
Shipping across EgyptDelivered to your door
Cash on deliveryPay when your order arrives
Not sure it fits your project?Ask us on WhatsApp - we reply fast
Toshiba 2SK1356 N-Channel Power MOSFET 900V 3A TO-220F
The Toshiba 2SK1356 is a high-speed, high-voltage N-Channel power MOSFET designed for a wide range of power switching applications. This component is ideal for use in DC-DC converters, switch-mode power supplies, and motor control circuits. Its robust design ensures reliable performance with minimal lot-to-lot variations. The 2SK1356 is an enhancement-mode transistor, offering low on-resistance and fast switching speeds.
Features:
- High Voltage Capable of handling a drain-source voltage of up to 900V.
- High-Speed Switching Designed for rapid switching applications to improve efficiency.
- Low On-Resistance Minimizes power loss and heat generation with a static drain-source on-resistance of less than 4.3Ω
- Enhancement Mode Features a low gate threshold voltage for easier control.
- Low Gate Charge Contributes to faster switching and reduced driver power requirements.
Specifications:
| Parameter | Value |
|---|---|
| Transistor Type: | N-Channel MOSFET |
| Drain-Source Voltage (Vdss): | 900 V |
| Continuous Drain Current (Id): | 3 A |
| Power Dissipation (Pd): | 40 W |
| Gate-Source Voltage (Vgss): | ±30 V |
| Static Drain-Source On-Resistance (Rds(on)): | < 4.3 Ω |
| Operating Junction Temperature (Tj): | 150 °C |
| Rise Time (tr): | 55 ns |
| Drain-Source Capacitance (Cd): | 120 pF |
Applications:
- Switching Power Supplies
- Motor Control
- Power Amplifiers
- Pulsed Power Applications
- Relay and Solenoid Driving
Package Contents:
- 1x Toshiba 2SK1356 N-Channel Power MOSFET 900V 3A TO-220F
Datasheet
