Technical Specifications
| Physical | |
| Color | Blue |
| Contact Plating | Tin |
| Mount | PCB, Through Hole |
| Technical | |
| Max Operating Temperature | 125 °C |
| Max Power Dissipation | 500 mW |
| Min Operating Temperature | -55 °C |
| Number of Turns | 1 |
| Power Rating | 500 mW |
| Resistance | 1 kΩ |
| Taper | Linear |
| Temperature Coefficient | 100 ppm/°C |
| Termination | Pin |
| Tolerance | 10 % |
| Voltage Rating | 300 V |
| Voltage Rating (AC) | 300 V |
| Voltage Rating (DC) | 300 V |
3386H-1-102 Datasheet
