Waterproof Female USB 2.0 Panel Mount Socket 4 Pin
Waterproof Female USB 2.0 Panel Mount Socket 4 Pin is commonly used to provide a secure external USB connection for power and data transfer in electronic enclosures, vehicles, and DIY projects, Rear Chassis Panel Mount.
20.00 EGP
Buy NowWaterproof Female USB 2.0 Panel Mount Socket 4 Pin
The Waterproof Female USB 2.0 Panel Mount Socket is a compact USB Type-A female connector designed for mounting on panels, enclosures, control boxes, and equipment housings. It features a 4-pin connection for standard USB 2.0 signals, including power, ground, and data lines. The integrated mounting tabs with screw holes provide a secure and stable installation.
Its panel-mount construction makes it suitable for applications where a USB port needs to be extended from inside an enclosure to an accessible external location. The protected connector housing helps improve durability for use in electronic equipment, automotive projects, industrial control boxes, and other applications requiring a reliable USB connection, Front Chassis Panel Mount.
Features:
- Female USB Type-A connector.
- USB 2.0 interface.
- 4-pin connection.
- Panel mount design.
- Screw mounting holes.
- Compact construction.
- Secure external USB connection.
- Supports power and data connections.
- Suitable for electronic enclosures and equipment.
Specifications:
| Specification | Value |
|---|---|
| Connector Type | USB Type-A Female |
| USB Version | USB 2.0 |
| Number of Pins | 4 Pins |
| Mounting Type | Panel Mount |
| Mounting Method | Screw Hole |
| Gender | Female |
| Connection Type | Power and Data |
| Housing Color | Black |
Pinout:
| Pin | Signal | Description |
|---|---|---|
| 1 | VBUS | +5V Power |
| 2 | D- | USB Data Negative |
| 3 | D+ | USB Data Positive |
| 4 | GND | Ground |
Applications:
- USB extension panels.
- Electronic enclosures.
- DIY electronics projects.
- Automotive electronics.
- Control boxes.
- Industrial equipment.
- Computer accessories.
- Embedded systems.
- USB power and data connections.
Package Includes:
- 1 × Waterproof Female USB 2.0 Panel Mount Socket 4 Pin.
