TS-3506 SMD Tactile Push Button 2Pin 3x4x2mm
The TS-3506 SMD Tactile Push Button 2 Pin 3x4x2mm 12VDC 50mA is a miniature surface-mount momentary switch designed for compact PCB layouts and modern electronic devices. With dimensions of 3mm × 4mm × 2mm, it provides an optimal balance between compact size and usability.
Features:
- Compact 3x4mm SMD footprint.
- 2-pin configuration for simple circuit design.
- Normally open (momentary) operation.
- Standard rating 12VDC 50mA.
- Reliable tactile feedback mechanism.
Specifications:
| Parameter | Value |
|---|---|
| Model Number | TS-3506 |
| Switch Type | Tactile Push Button (Momentary) |
| Mounting Type | SMD (Surface Mount) |
| Number of Pins | 2 |
| Contact Type | Normally Open (NO) |
| Rated Voltage | 12VDC |
| Rated Current | 50mA |
| Contact Resistance | ≤100mΩ |
| Insulation Resistance | ≥100MΩ |
| Operating Force | ~1.56N±0.5N |
| Travel Distance | ~0.25mm |
| Mechanical Life | ≥100,000 cycles |
| Operating Temperature | -25°C to70°C |
| Dimensions | 3mm × 4mm × 2mm |
Applications:
- Embedded systems and development boards.
- Consumer electronics interfaces.
- IoT and smart devices.
- Remote controls and keypads.
- Industrial control systems.
- DIY electronics and prototyping.
Package Include:
1x TS-3506 SMD Tactile Push-Button 2Pin 3x4x2mm
